在 NixOS 25.11 上运行 Niri
从 GDM 到 systemd 依赖地狱
使用 Niri 已有一个月，感到极大满足。
正好碰上放假，所以是时候该试试 NixOS1 了。
表现 #
- 登入 Niri 后有几率无法拉起 waybar / mako 等组件，提示 condition unmet 或 连不到 wl display
crash log 例
1May 01 08:13:25 qemu systemd[2030]: Starting Lightweight Wayland notification daemon...
2May 01 08:13:25 qemu systemd[2030]: Started polkit-mate-authentication-agent-1.service.
3May 01 08:13:25 qemu systemd[2030]: Started swaybg.service.
4May 01 08:13:25 qemu systemd[2030]: Started swayidle.service.
5May 01 08:13:25 qemu systemd[2030]: Started Highly customizable Wayland bar for Sway and Wlroots based compositors..
6May 01 08:13:25 qemu swayidle[146979]: 2026-05-01 08:13:25 - [Line 1086] Unable to connect to the compositor. If your compositor is running, check or set the WAYLAND_DISPLAY environment variable.
7May 01 08:13:25 qemu swaybg[146974]: 2026-05-01 08:13:25 - [main.c:616] Unable to connect to the compositor. If your compositor is running, check or set the WAYLAND_DISPLAY environment variable.
8May 01 08:13:25 qemu systemd[2030]: swaybg.service: Main process exited, code=exited, status=1/FAILURE
9May 01 08:13:25 qemu systemd[2030]: swaybg.service: Failed with result 'exit-code'.
10May 01 08:13:25 qemu systemd[2030]: swayidle.service: Main process exited, code=exited, status=253/n/a
11May 01 08:13:25 qemu systemd[2030]: swayidle.service: Failed with result 'exit-code'.
12May 01 08:13:25 qemu mako[146986]: failed to create display
13May 01 08:13:25 qemu systemd[2030]: Started Lightweight Wayland notification daemon.
14May 01 08:13:25 qemu systemd[2030]: mako.service: Main process exited, code=exited, status=1/FAILURE
15May 01 08:13:25 qemu systemd[2030]: mako.service: Failed with result 'exit-code'.
16May 01 08:13:25 qemu polkit-mate-authentication-agent-1[146972]: cannot open display:
17May 01 08:13:25 qemu systemd[2030]: polkit-mate-authentication-agent-1.service: Main process exited, code=exited, status=1/FAILURE
18May 01 08:13:25 qemu systemd[2030]: polkit-mate-authentication-agent-1.service: Failed with result 'exit-code'.
19May 01 08:13:25 qemu waybar[146980]: cannot open display:
20May 01 08:13:25 qemu systemd[2030]: waybar.service: Main process exited, code=exited, status=1/FAILURE
21May 01 08:13:25 qemu systemd[2030]: waybar.service: Failed with result 'exit-code'.
22May 01 08:13:25 qemu xdg-desktop-portal-gnome[147020]: Failed to open service channel Wayland connection, portals dialogs may missbehave (Cannot invoke method; proxy is for the well-known name org.gnome.Mutter.ServiceChannel without an owner, and proxy was constructed with the G_DBUS_PROXY_FLAGS_DO_NOT_AUTO_START flag).
23May 01 08:13:25 qemu xdg-desktop-portal-gnome[147020]: Non-compatible display server, exposing settings only.
24May 01 08:13:25 qemu xdg-desktop-portal-gtk[147042]: cannot open display:
25May 01 08:13:25 qemu systemd[2030]: xdg-desktop-portal-gtk.service: Main process exited, code=exited, status=1/FAILURE
26May 01 08:13:25 qemu systemd[2030]: xdg-desktop-portal-gtk.service: Failed with result 'exit-code'.
27May 01 08:13:25 qemu systemd[2030]: Failed to start Portal service (GTK/GNOME implementation).- 登出 Niri 第二次尝试登录时 gdm 提示 Authentication error，界面无法操作，只能重启
display-manager.service解决
TL;DR #
- 等待 NixOS 推送 GNOME 50 (nixpkgs#501286)
写 systemd 服务时带上脑子
Phase I: almost timing #
P1 直觉上是送分题，也许是启动时存在某种 race，在 reach graphical-session.target 前加个延迟即可。
同时翻到了 NixOS 对 x11 session 下 DM 的 hack，写了一个 wrapper 用于拉起上述 target，可以通过设置
1{
2 systemd.services.display-manager.environment = {
3 XDG_CURRENT_DESKTOP = "X-NIXOS-SYSTEMD-AWARE";
4 };
5}绕过。显然 wayland 窗管并不吃这套，所以暂且不知 nixpkgs#493701 是何意味。
最终类似 niri#3177，增加妙妙检测如下：
1{
2 # idea from uwsm's wayland-session-waitenv.service
3 systemd.user.services.niri-waits-for-wldisp-env = {
4 after = [ "niri.service" ];
5 bindsTo = [ "niri.service" ];
6 partOf = [ "niri.service" ];
7 before = [ "graphical-session.target" ];
8 serviceConfig = {
9 Type = "oneshot";
10 RemainAfterExit = true;
11 ExecStart = pkgs.writeShellScript "niri-waits-for-wldisp-env" ''
12
13 for i in {1..5}; do
14 if ${pkgs.systemd}/bin/systemctl --user show-environment | grep -iq niri; then
15 niri_found=1; break
16 fi
17 sleep 0.2
18 done
19
20 if [ -z "$niri_found" ]; then
21 echo "niri not running" >&2
22 exit 0
23 fi
24
25 for i in {1..10}; do
26 ${pkgs.systemd}/bin/systemctl --user show-environment | grep -q '^WAYLAND_DISPLAY=' && exit 0
27 sleep 0.5
28 done
29
30 echo "WAYLAND_DISPLAY not imported after 5s" >&2
31 exit 1
32 '';
33 };
34 wantedBy = [ "niri.service" ];
35 };
36}重启 DM 后可以稳定拉起相关组件。看起来问题得到了解决，但此时下定论为时过早。
Phase II: GDM #
来到 P2，首先检视 Niri 的 ExecMain{Code, Status} 返回值，似乎一切正常。
GNOME 49 有一项行为变更 (gdm !289)，会话不再通过 dbus-run-session 启动。当然，niri-session 已经正确处理 dbus 连接，不过仍然值得一试：
1{
2 systemd.user.services.niri = {
3 serviceConfig = {
4 # restores gdm!289
5 ExecStart = [
6 ""
7 "${pkgs.dbus}/bin/dbus-run-session --dbus-daemon=${pkgs.dbus}/bin/dbus-daemon -- ${pkgs.niri}/bin/niri --session"
8 ];
9 };
10 };
11}不幸地，猜谜阶段到此结束。启用 GDM debug，观察日志输出，注意到：
1qemu systemd[1]: Started Session c19 of User gdm-greeter.
2qemu gdm[29190]: Gdm: GdmDisplay: Session never registered, failing
3qemu gdm[29190]: Gdm: Child process -29228 was already dead.
4qemu gdm[29190]: Gdm: GdmDisplay: Session never registered, failing
5qemu gdm[29190]: Gdm: Child process -29228 was already dead.当然上述片段是成文时去 journal 里扒拉来的。不过正是其中 session never registered 警告引起了笔者的注意，来自 gdm-display.c#L701，对应 session.registered$ 在此处检查。
走到这里基本就有数了。所谓人之初性本善，守序中立的做法自然是对照 50.x 把对应 行为 backport 下来，至少需要 gdm !285 !350；初步试了下是能够注册上，但还有别的问题。
起码尽力了，不得行就只能勉为其难按照一开始想好的答案来了（笑）
1diff --git a/daemon/gdm-local-display-factory.c b/daemon/gdm-local-display-factory.c
2index ad2e65cf7..11e0cea90 100644
3--- a/daemon/gdm-local-display-factory.c
4+++ b/daemon/gdm-local-display-factory.c
5@@ -621,11 +621,7 @@ on_display_status_changed (GdmDisplay *display,
6 break;
7 case GDM_DISPLAY_MANAGED:
8 #if defined(ENABLE_USER_DISPLAY_SERVER)
9- g_signal_connect_object (display,
10- "notify::session-registered",
11- G_CALLBACK (on_session_registered_cb),
12- factory,
13- 0);
14+ finish_waiting_displays_on_seat (factory, "seat0");
15 #endif
16 break;
17 case GDM_DISPLAY_WAITING_TO_FINISH:
18--
192.45.4
值得一提的是 nixpkgs 打补丁还算方便，增加 overlays 即可，如：
1{
2 # ..snip..
3
4 outputs = inputs@{ nixpkgs, ... }:
5 let
6 overlays = [(import ./pkgs {})];
7 in {
8 nixosConfigurations = {
9 qemu = nixpkgs.lib.nixosSystem {
10 modules = [
11 { nixpkgs.overlays = overlays; }
12 ];
13 };
14 };
15 };
16}对应 ./pkgs/default.nix 如下：
1# ..snip..
2
3final: prev:
4{
5 gdm = prev.gdm.overrideAttrs (old: {
6 patches = (old.patches or [ ]) ++ [
7 ./gdm-49.2/always-registered.patch
8 ];
9 });
10}Phase III: s-d dependency hell #
P2 得到了解决，但是不难发现还有惊喜：退出重进是正常了，但是 P1 重现，依然会有一半概率桌面组件拉不起来。
观察发现 Niri 退出后 graphical-session.target 仍然 active，因此再次进入桌面时我们的妙妙脚本无法起到延迟效果。Niri 的登出通过触发 niri-shutdown.target 进行，与前者 conflict，因此没道理出现这种情况。
为了更好观察退出行为，尝试直接停止 graphical-session.target，即
1{
2 systemd.user.services.niri = {
3 serviceConfig = {
4 ExecStop = [
5 ""
6 "/run/current-system/systemd/bin/systemctl --user stop graphical-session.target"
7 ];
8 };
9 };
10 systemd.user.targets.niri-shutdown = {
11 conflicts = lib.mkForce [ "niri.service" ];
12 };
13}行为上没有区别。那就故技重施，上检测：
1{
2 systemd.user.services.niri-waits-for-graceful-shutdown = {
3 serviceConfig = {
4 Type = "oneshot";
5 ExecStart = pkgs.writeShellScript "niri-waits-for-graceful-shutdown" ''
6
7 for i in {1..20}; do
8 systemctl --user is-active --quiet graphical-session.target || exit 0
9 sleep 0.5
10 done
11
12 echo "graphical-session.target does not shutdown after 10s" >&2
13 exit 1
14 '';
15 };
16 };
17 # systemd.user.services.niri = {
18 # serviceConfig = {
19 # ExecStop = [
20 # ""
21 # "/run/current-system/systemd/bin/systemctl --user stop graphical-session.target"
22 # ];
23 # };
24 # };
25 systemd.user.targets.niri-shutdown = {
26 # conflicts = lib.mkForce [ "niri.service" ];
27 after = lib.mkForce [ "niri-waits-for-graceful-shutdown.service" ];
28 wants = lib.mkForce [ "niri-waits-for-graceful-shutdown.service" ];
29 };
30}似乎也没有明显的延迟触发。
跟踪日志输出，注意到三者的停止顺序符合预期，但 ~1s 后 graphical-session.target 又重新启动，经过 ~5s 退出。非常明显，有服务给它拉起来了！
> systemctl --user list-dependencies --reverse graphical-session.target
graphical-session.target
● ├─niri.service
● ├─polkit-mate-authentication-agent-1.service
○ ├─swaybg.service
× ├─swayidle.service
● └─xdg-desktop-portal-gnome.serviceswaybg 和 swayidle 的服务配置都是从 Niri wiki: Example systemd Setup 上抄来的，删除 Requisite= 后不再出现在 dependents 列表中，问题终于彻底解决。
此外，GNOME Shell 下发现有部分组件尝试启动，Wants/WantedBy 应该为窗管的服务，例：
1@@ -23,7 +23,10 @@ lib.mkMerge [
2 # niri
3 programs.waybar = {
4 enable = true;
5- systemd.enable = true;
6+ systemd = {
7+ enable = true;
8+ targets = lib.mkForce [ "niri.service" ];
9+ };
10 };
11 home.packages = with pkgs; [ fuzzel swaybg ];
12
13@@ -49,7 +52,7 @@ lib.mkMerge [
14 Restart = "on-failure";
15 };
16 Install = {
17- WantedBy = [ "graphical-session.target" ];
18+ WantedBy = [ "niri.service" ];
19 };
20 };
21 }
聊天较为随意，提请读者注意区分 Nix DSL、nixpkgs 与 NixOS；图中指的是 NixOS ↩︎
